Industrial M400 SATA SSDs

SMART Modular’s M400 SATA SSDs are designed for demanding enterprise and industrial applications including servers, networking, and storage systems. It supports AES-256 hardware encryption and ATA security features as a Self-Encrypting Drive (SED), and integrates seamlessly into host systems without BIOS or driver modifications.

NVMSentry™ Firmware for Customization Support

NVMSentry provides the full package of advanced firmware features for specific customization requirements and optimized product performance. Incorporating SMART’s proprietary NVMSentry firmware along with a best-in-class SSD controller, the M400 SATA SSDs offer exceptional performance while providing the flexibility and optionality for mission critical applications.

SafeDATA™ Power Loss Data Protection Technology

The M400 SATA 2.5" SSDs and M.2 2280 SSDs are offered optional SafeDATA™ technology, which adds another layer of protection for data. SafeDATA technology is a robust system of hardware and firmware that have SMART SSDs operate safely during any events of unexpected power loss. It guarantees the end-to-end data integrity and prevents drive corruption due to the loss of critical data during the unexpected shut down.

AES-256 Encryption for Data Security

The M400 SATA SSDs come with AES 256 encryption and ATA security features commands for data security and data sanitization. AES is a hardware-based encryption method for converting data from an unencrypted into an encrypted format. 256 bits encryption key length makes it virtually impossible to decrypt the data without the original key.

1 DWPD (Drive Write Per Day)

SMART’s M400 SATA SSDs deliver high performance with endurance up to 1 DWPD for five years. DWPD allows users to calculate the number of times the drive can be written per day, based upon the JEDEC workload used to specify the TBW.

SEU Mitigation Technology

SEU poses a significant threat to electronic devices, particularly SSDs, by causing temporary errors due to cosmic rays from space or Alpha particles from radioactive impurities. Engineered with advanced SEU mitigation technology, SMART's M400 SATA SSDs deliver exceptional reliability and performance, for the most demanding environments. Learn More

● SMART’s Proprietary NVMSentry Firmware

● Single Event Upset (SEU) Mitigation Technology

● Optional SafeDATA Power-Loss, Data-Protection Technology for 2.5" and M.2 2280 Form Factors

● 1 DWPD For Five Years

● TCG OPAL 2.0 and AES 256 Encryption

● End-to-End Data Path Protection

● Quality of Service (QoS) with 3 Nines of Latency Consistency

● Support I-Temp (-40°C to +85°C)
