DC4800 | PCIe NVMe | U.2 SSD

DC4800

SMART’s DC4800 PCIe Gen4 NVMe SSDs are designed to meet the increasing demands placed on storage systems in hyperscaler, hyper-converged, enterprise, and edge data centers.

SMART’s DC4800 SSDs deliver industry leading KIOPs/Watt performance with superior Quality of Service (QoS) across mixed application workloads. At the heart of the DC4800 SSDs is an innovative controller and firmware architecture that delivers ultra-low and consistent I/O latency with power consumption levels that virtually eliminate thermal throttling.

SMART Modular is listed as an OCP Solution Provider. The DC4800 Data Center SSD has been certified by OCP as an OCP INSPIRED product (https://bit.ly/45PLgtI).

Essentials
DC4800
3D TLC
PCIe Gen4 x4 NVMe 1.4
Performance
Up to 7100MB/s
Up to 4600MB/s
Up to 1490K IOPS
Up to 180K IOPS
1920GB
3840GB
7680GB
Reliability
1920GB: 4000 TBW
3840GB: 8000TBW
7680GB: 16000TBW
(JEDEC® Enterprise Workload)
> 2,000,000 hours
1
Environmental
1500G half-sine, 0.5 msec, 1 shock along each axis, X, Y, Z in each direction
20G 80-2000Hz, 1.5mm 20-80Hz, 3 axis
C-temp: 0℃ to +70℃
-40℃ to +85℃
40℃, Operation: 90% RH, Storage: 93% RH
Physical
100mm
69.85mm
15mm
SVU2Q7T68H1F2G217680GBC-temp (0˚C to +70˚C)
SVU2Q3T84H1F2G213840GBC-temp (0˚C to +70˚C)
SVU2Q1T92H1F2G211920GBC-temp (0˚C to +70˚C)
