ME2 | SATA | Slim SATA SSD
Slim SATA SSDs
SMART Modular世邁科技DuraFlash ME2 Slim SATA工業級固態硬碟採用最新一代3D NAND技術與獨家專利NVMSentry™韌體架構，並根據JEDEC JESD219A工作負載標準，提供5年使用期間每天可以整盤寫入 (DWPD) 1次的耐用度。在不需犠牲性能和可靠度的前提下，與之前64層和96層NAND技術相比，使用新一代NAND技術的固態硬碟將可提供更低單位位元成本。此外，優化後的NVMSentry韌體也能針對各種應用工作負載加強讀寫的一致性。
- 標準
- ME2
- eTLC
- SATA 3.0 6Gb/s
- 效能
- Up to 540MB/s
- Up to 460MB/s
- Up to 77K IOPS
- Up to 70K IOPS
- 240GB
480GB
960GB
1920GB
- 可靠度
- 240GB: 510TBW
480GB: 1015TBW
960GB: 2275TBW
1920GB: 3755TBW
(JEDEC® Enterprise Workload) - > 2,000,000 hours
- 1
- 環境耐受度
- 1500G half-sine, 0.5 msec, 1 shock along each axis, X, Y, Z in each direction
- 20G 80-2000Hz, 1.52mm 20-80Hz, 3 axis
- C-temp: 0℃ to +70℃
I-temp: -40℃ to +85℃ - -40℃ to +85℃
- 40℃, Operation: 90% RH, Storage: 93% RH
- 尺寸
- 36.7mm
- 54mm
- 4mm
| SRSLM1920FCM2AC3 | 1920GB | C-Temp (0˚C to +70˚C) |
| SRSLM1920FIM2AC3 | 1920GB | I-Temp (-40˚C to +85˚C) |
| SRSLM960GFCM2AC3 | 960GB | C-Temp (0˚C to +70˚C) |
| SRSLM960GFIM2AC3 | 960GB | I-Temp (-40˚C to +85˚C) |
| SRSLM480GFCM2AC3 | 480GB | C-Temp (0˚C to +70˚C) |
| SRSLM480GFIM2AC3 | 480GB | I-Temp (-40˚C to +85˚C) |
| SRSLM240GFCM2AC3 | 240GB | C-Temp (0˚C to +70˚C) |
| SRSLM240GFIM2AC3 | 240GB | I-Temp (-40˚C to +85˚C) |
